Product Description
Scotchlok Adapter
- 600V-rated for building wire and 1000V for signs, fixtures or luminaires
- Features a non-insulated, butted-seam barrel
- Interconnects two connectors that are already attached to wires
- Made of durable brass for good conductivity and tin-plated for corrosion resistance
- Mates with 0.25-in wide female and male tab
- Perfect for various wire tapping and splicing applications
- UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
- Withstands a maximum temperature of 347 degrees F (175 degrees C) for bare terminals
3M Scotchlok Non-Insulated Double Male-Female Adapter has a non-insulated, butted-seam barrel. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
For more information about Scotchlok Adapter, visit the official 3M website.
About JAM Industrial Supply of Ohio
Locally owned and operated in Canton, OH, JAM Industrial Supply, LLC has been a 3M Premier distributor and industrial supplier for over 20 years. With our vast network of vendors, we are able to supply the industry’s best products, information, delivery and prices to our customers.
Can’t find what you need? Contact us today for assistance.
Buying in bulk? Apply for special discounts on large quantity orders.
Additional information
| Unit of Measure | |
|---|---|
| Product Id | |
| Part Number | |
| UPC | |
| Per Case | |
| Weight | 1.802 lbs |
| Brand | |
| Connection Width | 0.25 in |
| Barrel Style | Butted |
| CSA File Number | LR22190 |
| Disconnect Type | Female|Male |
| Fastener Orientation | Double Male-Female |
| Insulation Material | Non-insulated |
| Material | |
| pa_mates-with-female-male-tab-width-w | |
| pa_maximum-insulation-outer-diameter-metric | |
| pa_maximum-insulation-outside-diameter | |
| pa_maximum-operating-temperature-celsius | |
| pa_maximum-operating-temperature-fahrenheit | |
| pa_maximum-recommended-voltage-rating | |
| Maximum Voltage Rating | 600 to 1000 V |
| Overall Length (Imperial) | 0.76 in |
| Pad Width | 0.25 in |
| Product Type | Connector |
| Terminal Style | Adapter |
| Terminal Type | Adapter |
| UL File Number | E70512 |
| Units Per Case | |
| Dimensions | 4.4 × 3.2 × 3 in |
