Product Description
Advantages of 3M™ Scotchlok™ Electrical IDC 560N-BULK
- Brown polypropylene-insulated connector for parallel splicing
- Brass element construction for good conductivity and tin plating for corrosion resistance
- Accommodates 12 AWG solid/stranded, 10 AWG stranded
- UL Listed and RoHS 2011/65/EU Compliant
3M™ Scotchlok™ Electrical IDC 560N-BULK is a double run connector for parallel splicing. It electrically connects two run (through) wires while insulating the connection. It is suitable for general purpose electrical connections on an auto, boat, van or trailer. Polypropylene insulated, self-stripping and flame retardant.
3M™ Scotchlok™ Electrical IDC 560N-BULK is 600V rated for building wire and 1000V rated for signs, fixtures and luminaires. It withstands temperatures of 221 degrees F (105 degrees C). UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
About JAM Industrial Supply of Ohio
Locally owned and operated in Canton, OH, JAM Industrial Supply, LLC has been a 3M Premier distributor and industrial supplier for over 20 years. With our vast network of vendors, we are able to supply the industry’s best products, information, delivery and prices to our customers.
Additional information
| Weight | 18.4 lbs |
|---|---|
| Unit of Measure | |
| Per Case | |
| Product Id | |
| Part Number | |
| UPC | |
| Brand | |
| Color | |
| Conductor Sizes | 14 AWG (Stranded) 16 AWG 18 AWG |
| Connector Type | Double run or tap |
| Connector Style | Insulation displacement |
| Flame Retardant | Yes |
| Grease Filling Against Corrosion | No |
| Insulation Color | Brown |
| Insulation Outer Diameter | 0.145 in |
| Interrupt Free Shifting | No |
| Material | |
| Max. Number of Cores | 2 |
| Maximum Conductor Sizes | 14 AWG (Stranded) 16 AWG |
| Maximum Operating Temperature | 105 degrees C |
| Maximum Recommended Voltage Rating | 600 V |
| Minimum Conductor Sizes | 18 AWG |
| Moisture Resistant | No |
| Recommended Crimping Tool | E-9BM or 9 in. Linemans Pliers |
| Run Maximum Insulation Outer Diameter | 0.145 in |
| Tap Maximum Insulation Outer Diameter | 0.145 in |
| Type | |
| Voltage Application | Low voltage |
| Wire Connector Type | IDC connector |
