Product Description
3M™ Scotchlok™ Vinyl Insulated with Insulation Grip Female Disconnect attaches to the mating part with a tongue that slips over the male tab. It has a butted-seam barrel that is covered by a funnel-designed, rigid-molded, polyvinyl chloride sleeve which serves to guide the wire into position. The polyvinyl chloride sleeve provides electrical contacts and mechanical stress relief at the point of insulation. The vinyl-sleeve insulation is abrasion-resistant and flared to ensure easy crimping. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
Additional information
| Product Id | |
|---|---|
| Part Number | |
| Weight | 3 lbs |
| Brand | |
| Connection Width | 0.11 in |
| Maximum Conductor Size | .25 mm² |
| Minimum Conductor Size | .14 mm² |
| Barrel Inside Diameter | 0.055 Inch |
| Barrel Style | Butted |
| Disconnect Type | Female |
| Fastener Orientation | Female |
| Insulation Material | Vinyl with Insulation Grip |
| Mates with Female Width | 0.110 Inch |
| Mates with Male Tab Width (W') | 0.110 Inch |
| pa_maximum-insulation-outer-diameter-imperial | |
| Overall Length (Imperial) | 0.63 in |
| Solution for | Wireless Network: Infrastructure Accessories |
| Tab Width | 0.187 |
| Terminal Style | Standard |
| Terminal Type | Disconnect |
| Units Per Case |
