3M™ Double Coated Film Tape 9589, White, 3/4 in x 36 yd, 9 mil

For Industrial Use Only. Estimated Lead Time Is 5 Working Days.

3M™ Double Coated Film Tape 9589 features a high-density polyethylene carrier with synthetic rubber adhesive on a densified kraft paper liner. It combines high initial adhesion and good holding power to ensure it bonds to a variety of materials. The paper liner has been specially treated to improve its strength and removability characteristics. More Info

Manufacturer:
3M
Selling Unit:
Roll
Part #:
3MT-23204
Min. Order Quantity:
1
UPC:
021200232046
Min. Order Increment:
1
3M Stock #:
7000048619

3M™ Double Coated Film Tape 9589, White, 3/4 in x 36 yd, 9 mil is available for purchase in increments of 1

48 pieces per pack ($18.71 per piece)

Price:

$897.88

Product Description

Advantages of Double Coated Film Tape 9589

  • High density polyethylene carrier provides dimensional stability and tears by hand
  • Adhesive removes cleanly from many surfaces to ensure a relatively easy clean-up process
  • Excellent quick stick and high adhesion ensure a reliable bond to a variety of substrates
  • This tape is in compliance with the FDA 21 CFR 175.105 guidelines for indirect food contact

3M™ Double Coated Film Tape 9589 features a high-density polyethylene carrier with synthetic rubber adhesive on a densified kraft paper liner. It combines high initial adhesion and good holding power to ensure it bonds to a variety of materials. 3M specially treats the paper liner to improve its strength and removability characteristics.

Long-Lasting Performance
3M™ Double Coated Film Tape 9589 is a 9.0 mil double coated tape with a high tack synthetic rubber adhesive on a high density polyethylene (HDPE) carrier. 3M™ Adhesive 760 provides excellent quick stick and bonds together a wide variety of materials, with a build-up over 24 hours that allows for proper placement of bonded materials. It features excellent adhesion to both high surface energy and low surface energy substrates. Additionally, it is an excellent choice for many indoor and room temperature applications such as carpet installation. The HDPE carrier adds dimensional stability to aid in removal while also providing easier handling during slitting, lamination and die cutting, and it tears by hand for quick and easy application. The tape is mounted on a 3.7 mil 62 lb. densified kraft paper liner which has been specially treated to improve strength and removability from high internal strength surfaces. This tape can withstand short-term temperatures of up to 200°F.

Recommended Applications

  • Carpet installation
  • General industrial mounting, joining and splicing
  • Miscellaneous joining and holding where jobs require high initial tack
  • Die-cutting and laminating applications

Additional information

Weight 23.4672 lbs
Restriction

Unit of Measure

Part Number

Adhesion To Foam

Adhesion To Hse

Adhesion To Lse

Adhesion To Metal

Adhesive Peel Initial

Adhesive Peel Ultimate

Adhesive Thickness (mils)

Adhesive Type

Backside Adhesive Thickness (mils)

Backside Adhesive Type

Carrier Color

Carrier Material

Carrier Thickness (mils)

Chemical Resistance

China Rohs Below Mcv

Eu Rohs Compliant

Faceside Adhseive Thickness (mils)

Faceside Adhseive Type

Humidty Resistance

Liner Color

Liner Thickness

Liner Type

Color

Length

Length Metric

Thickness

Thickness Metric

Width

Width Metric

Master Size Width

Maximum Operating Temperature (fahrenheit)

Maxmum Operating Temperature (celsius)

Minimum Operating Temperature (fahrenheit)

Moisture Resistance

Nominal Adhesive Thickness (mils)

Plasticizer Resistance

Primary Liner

Primary Liner Thicknes (mils)

Secondary Liner

Shear Strength At 72 Degrees F

Solvent Resistance

Tape Thickness

Tape Type

Total Thickness

UPC

Uv Resistance

Data Sheets

Technical Data Sheets
