Product Description
Scotchlok Female QuickSlide Disconnect
- Nylon-insulated connector electrically taps into a wire in mid-span without cutting
3M Scotchlok Insulation Displacement Connectors 951, 952 and 953 are 600V rated for building wire and 1000V rated for signs, fixtures and luminaires. They withstand temperatures of 221 degrees F (105 degrees C). UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
For more information about Scotchlok Female QuickSlide Disconnect, visit the official 3M website.
About JAM Industrial Supply of Ohio
Locally owned and operated in Canton, OH, JAM Industrial Supply, LLC has been a 3M Premier distributor and industrial supplier for over 20 years. With our vast network of vendors, we are able to supply the industry’s best products, information, delivery and prices to our customers.
Can’t find what you need? Contact us today for assistance.
Buying in bulk? Apply for special discounts on large quantity orders.
Additional information
| Unit of Measure | |
|---|---|
| Product Id | |
| Part Number | |
| UPC | |
| Per Case | |
| Weight | 2.7 lbs |
| Brand | |
| Connection Width | 0.25 in |
| Maximum Conductor Size | 14 AWG |
| Minimum Conductor Size | 1 mm² |
| Barrel Style | Insulated Self-Stripping |
| CSA File Number | LR22190 |
| Color Code | Blue |
| Connection Type | T-tap |
| Connector Style | Insulation Displacement |
| Disconnect Type | Female |
| Fastener Orientation | Female |
| Flame Retardant | |
| pa_grease-filling-against-corrosion | |
| Insulation Color | Blue |
| Insulation Material | Nylon |
| pa_insulation-outer-diameter-imperial | |
| Interrupt Free Shifting | No |
| Material | |
| Max. Number of Cores | 1 |
| pa_maximum-insulation-outer-diameter-metric | |
| pa_maximum-insulation-outside-diameter | |
| pa_maximum-operating-temperature-celsius | |
| pa_maximum-operating-temperature-fahrenheit | |
| pa_maximum-recommended-voltage-rating | |
| Pad Width | 0.25 in |
| Product Color | Blue |
| Product Type | Disconnect |
| Terminal Type | T-tap |
| UL File Number | E23438 |
| Wire Connector Type | IDC Connectors |
| Dimensions | 9.3 × 6.3 × 6.5 in |
